LRP200000201 Issue A
Page 4 © Edwards Limited 2016. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Introduction
1.2.11 Seal liquid reservoir
1.2.12 Seal liquid heat exchanger
Refer to the manufacturer's instructions listed in Section 1.2.7.
1.3 Application
The pumping systems are suitable for a wide range of non-hazardous area applications across industrial markets.
Ensure that the pumping system is suitable for the application.
If there are doubts as to the suitability of the pumping system for the application, consult Edwards Applications
Engineers for advice.
LR1A800 (50/60 Hz); SHR2400 (60 Hz) HRC 180
LR1A1200 - LR1A1300 (50/60 Hz); SHR2750 (50/60 Hz), SHR2950 (50 Hz) HRC 230
SHR2950 (60 Hz) HRC 280
Table 2 - Seal liquid reservoir general technical data
Design pressure 0.5 barg
Design temperature 80 °C
LR1A200 - LR1A400; EHR2190 - EHR2390
Dimensions
Diameter 250 mm
Height 780 mm
Corrosion allowance 0 mm
Working volume 0.015 m
3
Mass 25.5 kg
LR1A500 - LR1A700; SHR2400
Dimensions
Diameter 356 mm
Height 924 mm
Corrosion allowance 0 mm
Working volume 0.043 m
3
Mass 48 kg
LR1A800 - LR1A1300; SHR2750 - SHR2950
Dimensions
Diameter 508 mm
Height 1380 mm
Corrosion allowance 1.5 mm
Working volume 0.100 m
3
Mass 110 kg
Table 1 - Drive coupling models (continued)
Pump model Drive coupling model
