Edwards STP-A1303 Series User Manual

STP Series Turbomolecular Pump
MT-00E-001-M
Page 29
INSTALLATION OF THE STP CONTROL UNIT
3
3 INSTALLATION OF THE STP CONTROL UNIT
This section is extracted from the STP Control Unit Instruction Manual (C). The Applicable control
unit differs depending upon the STP pump model. Refer to "TECHNICAL DATA" in the STP Pump
Instruction Manual (B). For full details, read each of the STP Control Unit Instruction Manual (C).
3.1 STP control unit
WARNING
A hazardous live voltage may exist at the connectors that are marked .
DO NOT touch the terminal. Doing so may result in electric shock. When
connecting/disconnecting the terminal connections, always power OFF (turn the
MAIN POWER "OFF") and isolate (Lockout/Tagout) the electrical energy source,
water and gas, and other energy sources on the vacuum equipment. Failure to do so
may cause the STP pump to rotate accidentally, which may injure operators
seriously or result in electric shock.
WARNING
DO NOT remove the connecter while the pump is rotating. The voltage might be
output to connector according to the rotational speed, and it causes the electric
shock or the failure.
The Applicable STP control unit differs depending upon the STP pump model. Refer to "TECHNICAL
DATA" in the STP Pump Instruction Manual (B).
3.1.1 SCU-350 series
a) Front panel
b) Rear panel
Figure 18 - SCU-350 series
