8.4.1 Interface RS232
The following chart indicates the modulation of RS232 interfaces:
Fig. 6: RS232
interface
modulations
Baud-Rate
2400 bps
Date length
8 Bits
Stop bit
1 Bit
Parity
no
For connection just use the cords which are described under the chapter
„accessories”.
Fig. 7: USV –
interne internal
wiring of the
communication
interface
Pin:
Configuration:
2
RS232
Data transfer (Tx)
3
RS232
Data receipt (Rx)
5
RS232
GND (reference)
