6.5 Functions of the Keys Inputs in1...i10
Function with or without control panel
Parameter
Input 1
selectable input functions
0... 98
(in1)
240
Input 2
“ “
0... 98
(in2)
241
Input 3
“ “
0... 98
(in3)
242
Input 4
“ “
0... 98
(in4)
243
Input 5
“ “
0... 98
(in5)
244
Input 6
“ “
0... 98
(in6)
245
Input 7
“ “
0... 98
(in7)
246
Input 8
“ “
0... 98
(in8)
247
Input 9
“ “
0... 98
(in9)
248
Input 10
“ “
0... 98
(i10)
249
See List of Parameters for possible input functions of the keys.
6.6 Positioning speed
Function with or without control panel
Parameter
Positioning speed
(n1)
110
The positioning speed can be set using parameter 110 on the control within a range of 70...390 RPM.
6.7 Maximum Speed Compatible with the Sewing Machine
The maximum speed of the machine is determined by the selected pulley and by the following settings:
 Set the maximum speed using parameter 111 (n2)
 Set the maximum speed limitation to the specific level according to the application as described in chapter
"Direct Input of Maximum Speed Limitation (DED)".
6.8 Maximum speed
Function with or without control panel
Parameter
Maximum speed
(n2)
111
NOTE
See instruction manual of the sewing machine manufacturer for the maximum speed of the sewing machine.
NOTE
Select the pulley such that the motor runs at approx. 4000 RPM with max. number of stitches.
When programming 3-digit or 4-digit parameter values on the control (without control panel), the 2-digit or 3-digit
values displayed must be multiplied by 10.
