2.1 Special Accessories
The special accessories available ex works allow the augmentation and enhancement of functions, operating,
connecting, and mounting options.
Since the range of available components is continually expanded, we kindly ask you to contact us in case of
need.
Control panel Variocontrol V810
Control panel Variocontrol V820
Control panel Variocontrol V850
Control panel Variocontrol V900 (only in conjunction with compiler programming)
Reflection light barrier module LSM002
Hall sensor module HSM001
EFKANET Interface IF232-USB
Adapter cord for the connection of light barrier module and/or Hall sensor module
HSM001 and/or pulse encoder IPG001 and/or EFKANET
Compiler C200 for programming additional functions
Adapter cord for the connection of sockets B18 each on the SM210A stepping motor
control and on the control described here (see connection scheme in the separate
instruction manual “General Operation “)
Actuating solenoid type EM1.. (for e. g. sewing foot lifting, backtacking, etc.)
Extension cable approx. 1000 mm long for commutation transmitter DC15..
Extension cable approx. 1000 mm long for Netz DC15.. line
Potential equalization cord 700 mm long, LIY 2.5 mm
2
, gray, with spades on both
sides
Actuator (analog) type EB401
Foot control type FB302B with three pedals for standing operation, with approx.
1400 mm connecting cable and plug
Fitting piece for position transmitter
Knee switch type KN3 (pushbutton) with cord of approx. 950 mm length without plug
Knee switch type KN19 (pushbutton) with cord of approx. 450 mm length without
plug
Undertable mounting kit for DC15..
Undertable mounting kit (reinforced) for DC15..
please indicate line
voltage and sewing light
voltage (6.3V or 12V)
9-contact SubminD male connector
9-contact SubminD female connector
Half-shell housing for 9-contact SubminD
37-contact SubminD male connector, complete
Single pins for 37-contact SubminD with strand of 50 mm length
