Efka dc1550 - Analog Actuator Configuration

Instruction Manual
- 48 -
Table: Coding of the Pedal Steps
Pedal step
D
C
B
A
-2
H
H
L
L
Full heelback
(e. g. initiating the seam end)
-1
H
H
H
L
Slight heelback
(e. g. sewing foot lifting)
0
H
H
H
H
Pedal in pos. 0 (neutral)
½
H
H
L
H
Pedal slightly forward
(e. g. sewing foot lowering)
1
H
L
L
H
Speed stage
1
(n1)
2
H
L
L
L
Speed stage
2
3
H
L
H
L
Speed stage
3
4
H
L
H
H
Speed stage
4
5
L
L
H
H
Speed stage
5
6
L
L
H
L
Speed stage
6
7
L
L
L
L
Speed stage
7
8
L
L
L
H
Speed stage
8
9
L
H
L
H
Speed stage
9
10
L
H
L
L
Speed stage
10
11
L
H
H
L
Speed stage
11
12
L
H
H
H
Speed stage
12
(n2) Pedal completely
Function with or without control panel
Parameter
Selectable pedal functions
(-Pd)
019
The effect of pedal actuation on the drive functions can be set using parameter 019:
019 = 0
Pedal in pos. -1 blocked in the seam. But with pedal in pos. -2 sewing foot lifting is possible in the
seam (function active whenever the light barrier is On).
019 = 1
With pedal in pos. -1 sewing foot lifting is blocked in the seam.
019 = 2
With pedal in pos. -2 thread trimming is blocked (function active whenever the light barrier is On).
019 = 3
The functions “pedal in pos. –1” and “pedal in pos. –2” are active.
019 = 4
The functions “pedal in pos. –1” and “pedal in pos. –2” are blocked in the seam (function active
whenever the light barrier is On).
Function with or without control panel
Parameter
Speed stage graduation
(nSt)
019
The pedal characteristics (speed change from stage to stage) can be varied.
Possible characteristic curves: - linear
- progressive
- highly progressive
7.25.2 Analog actuator
Function with or without control panel
Parameter
Characteristic of the "analog pedal"
(APd)
026
The effect of pedal actuation on the drive functions can be set using parameter 026:
026 = 0
Analog function off
026 = 1
12-level selected, like prior pedal function of the digital actuator.
026 = 2
continuously variable
026 = 3
24-level
026 = 4
60-level (progressive)
026 = 5
60-level (progressive)
