7.16 Light barrier
Function with or without control panel
Parameter
Light barrier On/Off
009
Function with control panel
V820/V850
Light barrier covered/uncovered On
Light barrier uncovered/covered On
Light barrier Off
right-hand arrow above key On
left-hand arrow above key On
both arrows Off
Key 3
The light barrier function at the input of socket B18/5 is active only if parameter value 239 = 0.
7.16.1 Speed after Light Barrier Sensing
Function with or without control panel
Parameter
Speed after Light Barrier Sensing
(n5)
114
7.16.2 General Light Barrier Functions
Function with or without control panel
Parameter
Light barrier compensating stitches
Number of light barrier seams
Light barrier sensing uncovered/covered
Start of sewing blocked/unblocked with light barrier uncovered
Light barrier seam end with thread trimming On/Off
Speed of the light barrier compensating stitches
(LS)
(LSn)
(LSd)
(LSS)
(LSE)
(PLS)
004
006
131
132
133
192
 After sensing the seam end, the compensating stitches are counted at light barrier speed.
 Suspension of the procedure with pedal in pos. 0 (neutral). Interruption of the procedure with pedal in pos. -
2.
 The thread trimming operation can be disabled using parameter 133, regardless of the setting of key 5 on
the V820/V850 control panel. Stop in the basic position.
 Programming of max. 15 light barrier seams depending on the setting of parameter 006 with stop in the
basic position. Thread trimming after the last light barrier seam.
 Light barrier sensing uncovered or covered at the seam end can be selected using parameter 131.
 Start blockage with light barrier uncovered programmable using parameter 132.
 Speed selection pedal controlled / n5 during the light barrier compensating stitches using parameter 192.
The light barrier compensating stitches can be programmed and varied using the above parameters directly on
the control or on a connected V810/V820/V850 control panel.
For fast operator information (HIT) when using the V820/V850 control panel, the value of the function switched
on using key 3 can be displayed for approx. 3 seconds. During this time, the value can be varied directly by
pressing key + or -.
When using the V820/V850 control panel, direct access by means of the function key (key 9) is possible.
Function with control panel
Parameter
Start of sewing blocked with light barrier uncovered On/Off
(-F-)
008 = 3
