4.6 Electrical connections
WARNING!
All electrical work must only be carried out by qualified electrical techni-
cians in accordance with the relevant legal provisions.
Laying cables incorrectly or using the wrong cable size may result in a
fire hazard.
All connected cables must have sufficient insulation and adequate proof
voltage, and the connectors must be scoop-proof. The laying of un-
insulated cables and pins is not permitted.
INFO:
Use the cable harness supplied to connect the device.
The charge line must be connected to the battery using a fused circuit.
Always connect both charge lines (sensor line and power line).
Preferably run separate lines for charging (power) and for voltage meas-
uring (sensor) to the battery, otherwise the flow of current will cause
false voltage readings.
