Surge
IEC 61000-4-5
Line to line:
±0.5kV, ±1kV
Line to earth:
±0.5kV, ±1kV,
±2kV
Line to line:
±0.5kV, ±1kV
Line to earth:
±0.5kV, ±1kV,
±2kV
Mains power quality should
be that of a typical
commercial or hospital
environment.
Voltage dips,
short
interruptions
and
voltage
variations on
power supply
lines
IEC 61000-4-11
0% UT; 0.5 cycle
at 0°, 45°, 90°,
135°, 180°, 225°,
270°, and 315°
0% UT; 1 cycle
and 70% UT;
25/30 cycles
sine phase at 0°
0% UT; 250/300
cycle
0% UT; 0.5 cycle
at 0°, 45°, 90°,
135°, 180°, 225°,
270°, and 315°
0% UT; 1 cycle
and 70% UT;
25/30 cycles
sine phase at 0°
0% UT; 250/300
cycle
Mains power quality should
be that of a typical
commercial or hospital
environment. If the user of
devices require continued
operation during power mains
interruptions, it is
recommended that devices
be powered form an
uninterruptible power supply
or a battery
Power
frequency
magnetic field
IEC 61000-4-8
30 A/m
50Hz or 60Hz
30 A/m
50Hz or 60Hz
Power frequency magnetic
field should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
Note: UT: rated voltage(s); E.g. 25/30 cycles means 25 cycles at 50Hz or 30 cycles at 60Hz
Guidance and manufacturer’s declaration – electromagnetic immunity
The Ultra X is intended for use in the electromagnetic environment specified below. The
customer or the user of the Ultra X should assure that it is used in such an environment.
Immunity test
IEC 60601 test
level
Compliance level
Electromagnetic environment -
guidance
