Recommended separation distances between portable or mobile RF communication equipment
and the EX3242-3D
The EX3242-3D is intended for use in an electromagnetic environment in which radiated RF disturbances are
controlled. The customer or the user of the EX3242-3D can help prevent electromagnetic interference by maintaining
a minimum distance between portable and mobile RF communications equipment (transmitters) and the EX3242-3D.
Immunity to proximity elds from the following RF wireless communication equipment has been conrmed:
Test
frequency
(MHz)
Bandwidth
a)
(MHz)
Service
a)
Modulation
b)
Maximum
power
(W)
Minimum
separation
distance
(m)
IEC /
EN60601
test level
(V/m)
Compliance
level
(V/m)
385 380 - 390 TETRA 400 Pulse modulation
b)
18 Hz
1.8 0.3 27 27
450 430 - 470 GMRS 460,
FRS 460
FM
±5 kHz deviation
1 kHz sine
2 0.3 28 28
710 704 - 787 LTE Band 13, 17 Pulse modulation
b)
217 Hz
0.2 0.3 9 9
745
780
810 800 - 960 GSM 800 / 900,
TETRA 800,
iDEN 820
CDMA 850,
LTE Band 5
Pulse modulation
b)
18 Hz
2 0.3 28 28
870
930
1720 1700 - 1990 GSM 1800;
CDMA 1900;
GSM 1900;
DECT;
LTE Band 1, 3, 4,
25;
UMTS
Pulse modulation
b)
217 Hz
2 0.3 28 28
1845
1970
2450 2400 - 2570 Bluetooth,
WLAN,
802.11 b/g/n,
RFID 2450,
LTE Band 7
Pulse modulation
b)
217 Hz
2 0.3 28 28
5240 5100 - 5800 WLAN 802.11 a/n Pulse modulation
b)
217 Hz
0.2 0.3 9 9
5500
5785
a) For some services, only the uplink frequencies are included.
b) Carrier waves are modulated using a 50 % duty cycle square wave signal.
The EX3242-3D is intended for use in an electromagnetic environment in which radiated RF disturbances are
controlled. For other portable and mobile RF communication equipment (transmitters), the minimum distance between
portable and mobile RF communications equipment (transmitters) and the EX3242-3D should be according to the
maximum output power of the communication equipment as recommended below.
Rated maximum
output power of
transmitter
(W)
Separation distance according to frequency of transmitter
(m)
150 kHz to 80 MHz
d = 1.2√P
80 MHz to 800 MHz
d = 1.2√P
800 MHz to 2.7 GHz
d = 2.3√P
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
1 1.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation distance “d” in meters (m)
can be estimated using the equation applicable to the frequency of the transmitter, where “P” is the maximum output power
rating of the transmitter in watts (W) according to the transmitter manufacturer.
Note 1 At 80 MHz and 800 MHz, the separation distance for a higher frequency range applies.
Note 2 These guidelines may not apply in all situations. Electromagnetic propagation is a󰀨ected by absorption and reec-
tion from structures, objects and people.
30
Appendix
