EKOM DK50 2V/50 - FAD Correction for Altitude

TECHNICAL DATA
06/2020 25 NP-DK50 2V 50, 2x2V 110-A-5_06-2020-MD
FAD correction of capacity for altitude
Capacity given in the form of FAD („Free Air Delivery“) applies to the following conditions:
Altitude
0 m.n.m.
Temperature
20°C
Atmospheric pressure
101325 Pa
Relative humidity
0%
To calculate FAD compressor capacity in dependence on altitude, it is necessary to apply correction
factor according to the following table:
Altitude [m.n.m.]
0 -1500
1501 - 2500
2501 - 3500
3501 - 4500
FAD correction factor
1
0,8
0,71
0,60
