EKOM DK50 2V/50 - Page 27

INSTALLATION
06/2020 27 NP-DK50 2V 50, 2x2V 110-A-5_06-2020-MD
Fig. 4: Manipulation with the compressor
DK50 2V/50
DK50 2x2V/110
 Remove transport fixing elements from the pumps (Fig. 5).
Prior to installation, ensure that the compressor is free of all transport packaging
and stabilizers to avoid any risk of damage to the product.
Remove fixing elements of the pumps once the compressor has been assembled
and balanced at the final installation place.
