EKOM DK50 2V/50 - Page 38

INSTALLATION
NP-DK50 2V 50, 2x2V 110-A-5_06-2020-MD 38 06/2020
14.2. Electrical diagrams
DK50 2V/50
6 - 8 bar, 8 - 10 bar
1/N/PE ~ 230V/50Hz, 230V/60Hz
ELEKTRICAL OBJECT OF 1st. CAT.
DK50 2V/50/M
6 - 8 bar, 8 - 10 bar
1/N/PE ~ 230V/50Hz, 230V/60Hz
ELEKTRICAL OBJECT OF 1at. CAT.
