TECHNICAL DATA
8 SM-DK50 DS-EN-20_02-2016
3. TECHNICAL DATA
TYPE DK50 DS
VERSION basic standard advanced
Outlet flow at pressure 3.5 bar (51 psig) Liters/min 40
50
60
Peak flow 200* L/min
( 7 Cft/min
)
Voltage / Frequency / Nominal current V/Hz/A
230/50 / 2.8
230/60 / 2.8
120/60 / 5.6
120/60 / 5.6 UL model
100/50-60 / 5.6
230/50 / 2.8
230/60 / 2.8
120/60 / 5.6
100/50-60 / 5.6
230/50 / 3.3
230/60 / 3.9
120/60 / 6
100/50-60 / 6
Air filtration
m
5
Pressure dew point at 40 L/min
( 1.4 Cft/min), 3 bar( 43.5 psig ), 20°C (68°F)
5°C (9°F) below the ambient temperature
10°C (18°F) with membrane dryer (optional)
Outlet connection
DISS 1160-A (3/4"-16 UNF)
optional NIST (EN 739)
Sound level dB(A)
50
51 / 60 Hz
50
51 / 60 Hz
51
52 / 60 Hz
Mode of operation Continuous - S1
Separation of condensed water Automatic
Indication of drying
Yellow (working pressure < 4 bar (58 psig) )
Green (working pressure ≥ 4 bar (58 psig) )
Low pressure alarm Decrease in outlet pressure under 2.1 bar ( 30.5 psig )
Cooling failure alarm Increase in internal temperature above 80°C (176°F)
Outlet pressure
3.0 bar (43 psig)
Adjustable to max. 3.5 bar (51 psig)
Automatic start up pressure (backup)
Decrease in pressure in the central air line under
2.8 bar ( 40.6 psig)
Air tank capacity 2 L (0.61gall UK)
Pressure range 5 bar ( 72.5 psig ) – 6.5 bar ( 94 psig)
Operating pressure of safety valve 7 bar ( 101.5 psig )
Adjustment of outlet air pressure Pressure regulator
Dimensions of compressor w x d x h 445 x 355 x 440 mm ( 17.5 x 14 x 17 in )
Dimensions of compressor with weels w x d x h 470 x 380 x 520 mm ( 18.5 x 15x 20.5 in )
Dimensions of compressor with trolley w x d x h 535 x 575 x 1054 mm ( 21 x 22,5 x 41.5 in )
Dimensions of packaging w x d x h 510 x 480 x 470 mm ( 20 x 19 x 18.5 in )
Dimensions of packaging 560 x 630 x 760 mm ( 22 x 25 x 30 in )
Net weight 34 kg ( 75 lbs )
Net weight of compressor with weels 36 kg ( 80 lbs )
Net weight of compressor with trolley 45 kg ( 99 lbs )
Gross weight 41 kg ( 91 lbs )
Gross weight of compressor with weels 43 kg ( 95 lbs )
Gross weight of compressor with trolley 60 kg ( 132 lbs )
Implementation according to EN 60601-1, EN 12021 Type B class I.
Classification acc. to MDD 93/42 EEC, 2007/47 EC II b
* With 0.6 bar pressure drop (8.7 psig)
Climatic conditions for storage and transport
Temperature –25°C to +55°C (-13°F to +131°F), 24 hrs +70°C (+158°F)
Relative air humidity 10% to 90 % (no condensation)
Relative air humidity for seaworthy packing 10% to 100% (with condensation)
Climatic conditions for operation
Temperature +15°C to +40°C (+59°F to +104°F)
Relative air humidity up to +95%
IPX0 Rating
