EKOM DK50 User Manual (English)

Other manuals for EKOM DK50

Service Manual20 pages

Installation, Operation And Maintenance Manual136 pages

Operation Manual17 pages

Questions and Answers:

A
Anthony MclaughlinAug 18, 2025
Why does my EKOM DK50 Air Compressor often switch on?
- O
  Oscar AndersonAug 18, 2025
  Your EKOM Air Compressor might be frequently turning on due to several reasons. It could be caused by an air leak in the pneumatic distribution system, which means you should check the system and seal any loose joints. Another cause might be a leaking non-return valve; in this case, try cleaning the valve, replacing the seals, or replacing the entire valve. Finally, a large volume of condensed liquid in the pressure vessel could be the reason; try draining the condensed liquid.
C
Christopher EllisAug 20, 2025
What to do if my EKOM Air Compressor does not start?
- M
  Mark BookerAug 21, 2025
  If your EKOM Air Compressor isn't starting, there could be several reasons. First, check the voltage in the socket, as there might be no voltage in the pressure switch. Also, inspect the fuse and replace it if it's faulty, as the winding of the motor might be disconnected, or the thermal protection might be damaged. Another possible cause is a faulty capacitor, which would need replacement. In case of seizure of the piston or another rotary part, replace the damaged parts. Finally, check the function of the pressure switch, because it might not be switching on, or it could be switched to the “0“ position.
C
Calvin WrightAug 23, 2025
Why is my EKOM Air Compressor running for a prolonged time?
- A
  Amanda JonesAug 23, 2025
  An EKOM Air Compressor running for a long time can stem from several issues: an air leak in the pneumatic distribution system (check and seal loose joints), a worn piston ring (replace it), a contaminated filter (replace it with a new one), or a defective solenoid valve (repair or change the valve).
J
Jesse CastroAug 26, 2025
How to fix a noisy EKOM DK50 Air Compressor (knocking, metal noises)?
- J
  Jeffrey RiveraAug 26, 2025
  If your EKOM Air Compressor is making knocking or metallic noises, it might be due to a damaged bearing of the piston, piston rod, or motor bearing, in which case you should replace the damaged bearing. Another possibility is a loose or cracked spring, which would also require replacement.
L
Lori EstradaAug 28, 2025
Why won't my EKOM DK50 Air Compressor start?
- C
  Cynthia HernandezAug 28, 2025
  Your EKOM Air Compressor might not start due to several reasons. First, check if the main circuit breaker in the distribution is turned off. Then, ensure the electrical supply is connected and the voltage is correct. Also, verify that the terminals in the distribution box are securely fastened. If these steps don't resolve the issue, inspect the pressure switch for proper function and terminal connections; replace it if damaged.
D
davistamaraAug 30, 2025
What to do if my EKOM Air Compressor switches on and off frequently without using air?
- L
  Lisa HodgesAug 30, 2025
  If your EKOM Air Compressor cycles frequently without air consumption, it could be due to several issues. Begin by checking the pneumatic distribution for air leaks and tighten any loose connections. Next, inspect the reverse valves for tightness, cleaning them if necessary, and replace if damaged. Also, examine the solenoid valves for leaks after regeneration and clean or replace if needed. Finally, check the pressure switch and safety valve for tightness and proper function; clean or replace them if they are faulty.
T
tyroneprattSep 2, 2025
How to improve the performance of my EKOM DK50 if the cycle of operation is prolonged?
- H
  hsimmonsSep 2, 2025
  If your EKOM Air Compressor's performance is reduced and the cycle takes longer, start by checking the aggregate bonds for tightness and tighten any loose ones. Replace worn piston rings. Replace any damaged sealing material between the cylinder head and valve board, and tighten it. Finally, replace any contaminated input filter and prefilter with new ones.
M
Mark LongSep 4, 2025
What to do if some aggregates of EKOM DK50 Air Compressor don't start but the signal light is on?
- M
  Michael LopezSep 4, 2025
  If some aggregates of your EKOM Air Compressor don't start but the signal light is on, it could be due to a few reasons. First, check the network voltage to ensure there is an electric energy supply to the engine. Next, inspect the contactor, time relay (for 3 or more aggregates), and thermal relay (for 3 aggregates on top of each other), replacing any damaged components. Also, check and fasten any released terminals on the engine's terminal board, replacing any broken ones. If these don't work, the engine winding or thermal protection might be damaged, requiring a motor replacement. Lastly, check for seized pistons or other movable parts, and replace any damaged parts.
M
matthew02Sep 9, 2025
How to prevent my EKOM Air Compressor from overheating?
- C
  Christine JacksonSep 9, 2025
  To prevent your EKOM Air Compressor from overheating, ensure the room has sufficient aeration to provide suitable surrounding conditions. If the compressor aggregate's cooling valves or cooler aren't working, exchange the false blowers. If the problem persists, exchange the false thermal switch.
S
stephanie64Sep 12, 2025
Why is the drying unit of my EKOM DK50 Air Compressor noisy?
- D
  Donald DavisSep 12, 2025
  If the drying unit of your EKOM Air Compressor is noisy, it could be due to a false solenoid valve, which should be replaced. Alternatively, the damping substance in the condensate tank may be damaged and needs replacement. Another possible cause is a damaged pressure hose, which also needs to be replaced.

EKOM DK50 Specifications

General

Brand	EKOM
Model	DK50
Category	Air Compressor
Language	English

Summary

Important Information

1. Conformity With the Requirements of European Union Directives

Confirms product compliance with EU Medical Device Directive.

2. Intended Use

Specifies the compressor's purpose as a source of clean, oil-free compressed air.

3. Contraindications and Side-Effects

States that no contraindications or side-effects are known for the product.

4. Warnings and Symbols

Explains symbols used in the manual, device, and packaging for important information.

5. Warnings

Provides general warnings and safety precautions for product use and maintenance.

6. Storage and Transport

Details guidelines for safe storage and transport of the compressor.

7. Technical Data

Lists key technical specifications and operating parameters of the compressor.

8. Product Description

Describes the physical characteristics and variants of the DK50 compressor.

9. Function

Explains the operational principle and working mechanism of the compressor.

10. Pneumatic Diagram

Provides a schematic diagram illustrating the pneumatic system of the compressor.

Installation

11. Conditions for Use

Outlines the environmental and installation requirements for operating the compressor.

12. Placement of the Compressor

Provides instructions and considerations for positioning and securing the compressor.

13. Pneumatic Connections

Details how to connect the compressed air outlet to external devices.

14. Electrical Connection

Guides the user on safely connecting the compressor to the electrical mains.

15. Connection Diagram

Presents the electrical wiring diagram for the compressor's components.

Operation

16. Commissioning

Explains the steps and checks required for initial setup and starting the compressor.

17. Switching the Compressor On

Details the procedure for starting and operating the compressor.

Maintenance

18. Device Maintenance

Outlines general procedures and warnings for maintaining the compressor.

18.1. Maintenance Intervals

Specifies the recommended time intervals for various maintenance tasks.

18.2. Condensation Drain Valve

Describes the procedure for draining condensate from the air tank.

18.3. Safety Valve Check

Explains how to check the functionality of the safety valve.

18.4. Inspect the Device

Details steps for inspecting the compressor for leaks and overall performance.

18.5. Replacement of Filters of Air Pump

Provides instructions for replacing the air pump's filter elements.

18.6. Cleaning and Disinfection of Exterior Surfaces

Advises on appropriate cleaning and disinfection methods for the product exterior.

18.7. Stabilizing the Compressor Before Shipping

Describes how to secure the compressor for transport before shipping.

Troubleshooting

Compressor Does Not Start

Addresses common causes and solutions for the compressor failing to start.

Compressor Often Switches On

Discusses reasons and remedies for the compressor cycling on too frequently.

Prolonged Running of Compressor

Explains potential causes and solutions for the compressor running for extended periods.

Compressor is Noisy (Knocking, Metal Noises)

Identifies causes and provides remedies for unusual noise from the compressor.

Repair Service

Storage

Disposing of the Device

Annex / Anhang / Приложение / Príloha

22. Installation Record

A form to record details of the compressor's installation and initial setup.
