5. PREPARATION AND INSTALLATION ELBO CONTROLLI srl
Preset E346+/V+
13
5.5.2 REAR VIEW
(k)(l)
Start button
ON/OFF switch
Power cable for DYMO
mini printer, supplied
with the machine
DYMO mini printer
power connection
Ground terminal
24Vdc Power Supply
connection
Rotating spindle-holder
Vision system
illuminator
Vertical LCD Monitor
Touch-screen 15”
C-MOS image sensor
