5. PREPARATION AND INSTALLATION ELBO CONTROLLI srl
Preset E346+/V+
15
Also, on the rear panel, the attachment is available to power the DYMO mini printer (optional) with the
relative cable supplied.
5.7.1 USB-RJ45 HUB
In the support column of the LCD monitor, there is a HUB equipped with:
• 3 USB ports for connecting any external peripherals (e.g. mouse, keyboard, DYMO mini
printer, …).
• 1 RJ45 port to permit connection to the company data network.
DYMO mini printer
power connection
Power cable for DYMO
mini printer, supplied
with the machine
RJ45 connector
ethernet network input
Nr. 3 USB Port
