9. INSTALLING DYMO MINI PRINTER ELBO CONTROLLI srl
Preset E346+/V+
24
9. INSTALLING DYMO MINI PRINTER
9.1 DYMO CONNECTION
The E346+/V+ Presetter software is pre-programmed for printing on DYMO labels cod. 99012, 89x36
size via the DYMO labelling and printing machine, Label Writer 450.
If the labelling machine is purchased together with the presetter, it will already have been installed by Elbo
Controlli, so it can be connected to the power supply with the feeder and to the presetter via the USB port.
If the printer is purchased later, it requires installation through the following procedure:
• exit the measurement software by pressing the EXIT key
• connect the printer to the mains power supply with the feeder and to the presetter via the USB port,
then wait for the “installation is completed” message
• the Dymo labelling and printing machine is installed and ready to support printing of labels cod.
99012 from the presetter software
