In this environment you can set the following parameters :
● "Parking angle after homing": position at which the blades are placed following
completion of homing. The set position is a absolute quote referred to zero axis
blades (blades in contact)
●
● "Stop cycle Angle ": position to which the blades are positioned after completion or
interruption of a working cycle. The set position is a absolute value referred to zero
axis blades (blades in contact). The set value must be between 0 and a maximum
angle depending on the number of jaws of the machine (1 = 360 °, 180 ° = 2, 4 = 90
°)
● "Start welding Angle ": position of the knives at which the welding starts , ie the
phase of the cycle in which the tangential velocity of the blades must be perfectly
matched with the feed speed of the film. The set position is a absolute value
referred to zero axis blades (blades in contact)
● "Stop welding Angle ": position of the knives at which the welding ends, ie the
phase of the cycle in which the tangential velocity of the knives must be perfectly
matched with the feed speed of the film. The set position is a absolute value
referred to zero axis blades( blades in contact)
Setting of these data is possible only when a cycle is not in progress.
At the bottom of the screen a status bar displays messages on the current state of the
software. If an alarm occurs ,the status bar will display the message associated with the
current alarm and will display the red button on the right corner , pressing the red button
allows access to the environment of the alarm log
The left side of the screen contains buttons to access other areas of the software. From
top to bottom these buttons allow access to:
● main menù
● work environment
18
