the potentiometer), whereas in the second column is the "digital" value of 'corresponding
input. The analog inputs of TOP7 are 16-bit and then have a digital value that can have
values between 0 and 65535 points.
WARNING: depending on how it is connected , the potentiometer input has a scale of
values, in the sense that if the potentiometer is fed from this into TOP7 (5V) then it will
have a scale of 0 .. 32767 points, while if it is powered externally from 0 to 10V full scale
will be 0 .. 65535. The software is designed assuming that the potentiometer is fed to 5V.
The current status of the analog inputs is always managed and therefore can also be
monitored in the work cycle in progress.
The left side of the screen contains buttons to access other areas of the software. From
top to bottom these buttons allow access to:
● main menù
● digital I/O test
● analog inputs test (current environment)
● diagnostics
