USER MANUAL TOP7
SW: EFPLCAC0
Date:
15/02/2016
1.3 – LANGUAGE UPDATE WITH USB KEY
1. Copy on a USB key the file with extension LIN
2. Turn on the TOP7;
3. As soon as the blue progress bar appears , click on it
4. Digit password "2727" and press OK , to access the system menu
5. With USB key inserted , click on “Download PLC”
6. Select the LIN file containing the language and press the top right icon on the
screen (yellow folder with green arrow icon )
7. Wait for the message "Language OK" , then press OK
8. Click on “Start PLC”
9. Wait for start up
Access to the TOP7 system menu can also be executed by pressing “SYSTEM” within the
“Manufacturer parameters screen window”. In this case procedure 1.2 , can be executed
starting from point 5 : with USB key inserted , click on “Download PLC
