USER MANUAL TOP7
SW: EFPLCAC0
Date:
15/02/2016
● load a previously saved internal recipe or from USB stick. a list of recipes will be
displayed ( in the path selected ). To load the desired recipe simply select it and
press the upload button at the top right of the screen. To stop the operation without
performing any loading, press the button on the bottom right.
● save the current recipe in the internal archive or USB stick. A alphanumeric
keypad for entering the name of the recipe will be dispalyed . At this point you can
enter the name you want and press "ENTER" or stop the operation by pressing the
exit button at the top right.
● delete a recipe from internal archive or USB stick. A list of recipes will be displayed
( in the path selected ). To delete the desired recipe simply select it and press the
button at the top right of the screen. To stop the operation without selecting press
the delete button at the bottom right.
:The left side of the screen contains buttons for access to other areas of the software.
From top to bottom buttons respectively allow access to:
● main menù
● work environment (current environment)
● chain management
● cut / weld management
● manual
● printer management
3.3 - “ WORK ENVIRONMENT “ ( MANUAL )
14
