parameters" via the "Temperatures tolerance" field . WARNING: If you set this field
to zero temperatures control is not executed.
● "Temperature control not active": thermal system is not operating. In this state it
is NOT possible to start a cycle. To enable the temperature controllers , press the
ON button on the bottom right of the screen.
● "Incorrect parameters": the current recipe contains invalid values that prevent the
start of a cycle.
◦ "Chain pitch" set to zero
◦ "Package length" set to zero
◦ "Blade radius" set to zero
◦ “ Start welding angle “ is equal to “ End welding angle “
◦ “ Start welding angle “ set to a value less than zero
◦ “ Start welding angle “ set to a value exceeding 360 degrees
◦ “ End welding angle “set to a value less than zero
◦ “ End welding angle “ set to a value exceeding 360 degrees
◦ "Angle stop cycle" set to a value less than zero
◦ "Angle stop cycle" set to a value greater than the sealing jaws work period
(depending on the number of jaws)
● "Cycle in progress" work cycle running.
● "Pieces Completed": the machine has executed the set number of packs, and
stopped the work cycle. In this state it is NOT possible to start a new cycle.
At the top of the screen the name of the current recipe is displayed . To the right , three
buttons are available for recipe management. If you press one of three buttons and a USB
key is plugged in the TOP7, a page will be displayed so the operator can choose to
operate on the archive recipes , (press button with the TOP7 image) or USB key (press
button with the USB symbol).
From left to right the three buttons are used for :
13
