USER MANUAL TOP7
SW: EFPLCAC0
Date:
15/02/2016
In this environment you can only enter the parameter "Chain pitch", which must match the
mechanical measurement of linear distance between the chain links.
Setting this data is possible only when a cycle is not in progress.
At the bottom of the screen a status bar displays messages on the current state of the
software. If an alarm occurs ,the status bar will display the message associated with the
current alarm and will display the red button on the right corner , pressing the red button
allows access to the environment of the alarm log
The left side of the screen contains buttons to access other areas of the software. From
top to bottom these buttons allow access to:
● main menù
● work environment
● chain management (current environment)
● cut / weld management
● manual
● printer management
3.5 – CUT AND WELD
17
