USER MANUAL TOP7
SW: EFPLCAC0
Date:
15/02/2016
3.9 – DIAGNOSTICS
In this environment you can see some useful information for the diagnostics and the
current value of the total counter .
The diagnostic parameters "Time blades / chain" and "Time blades / notch" represent in
milliseconds, the time between the passage of the blades in front of their photocell and the
passage of the chain or the film in front of them. This value may be important in
diagnostics because speed must remain as constant as possible. If speed is not constant ,
