USER MANUAL TOP7
SW: EFPLCAC0
Date:
15/02/2016
CHAPTER 5 –CONNECTIONS
To manage the machine , the following configuration is necessary :
● N° 1 TOP7
● N° 1 EC7COM_013 (POWER SUPPLY AND COMMUNICATION BOARD ( WITH
CANBUS)
● N° 1 EC7DIO_022 (16 + 16 DIGITAL I/O BOARD ) – SLOT A
● N° 1 EC7AI_041 (ANALOG INPUTS BOARD ) – SLOT E
● N° 2 ECS_1066 (CONVERTERS TC J – 4-20Ma)
DIGITAL INPUTS 24V – EC7 DIO_022 – SLOT A
POLE
N°
DESCRIPTION
TEST I/O
1
FTC CUT AND WELD
1
2
FTC FILM
2
3
FTC CHAIN
3
4
EMERGENCY PUSH BUTTON (NC)
4
5
CARTER OPEN (NC)
5
6
Available
6
7
Available
7
8
Available
8
9
0 Volt shared inputs
10
NC
