USER MANUAL TOP7
SW: EFPLCAC0
Date:
15/02/2016
5. CHAIN: settings of the chain pitch ;
6. CUT / SEAL: configuration parameters of the knives;
7. PRINTERS: enabling and configuring any optional printers ;
8. MAIN MENU ': access to hardware test pages and machine parameters pages ;
9. DIGITAL I / O TEST : check and test of digital I / O system;
10. ANALOG INPUTS TEST : check and test of analog inputs (temperature sensors and
potentiometer for speed adjustment);
11. DIAGNOSTICS: “phase” values of the machine and total counter of cycles
performed;
12. MANUFACTURER PARAMETERS: configuration parameters of the machine and
access to loading / saving parameters on USB stick;
13. TEMPERATURE CONTROL: configuration and calibration of the temperature control
modules
14. AXIS: Set parameters for dynamic control of the axes
15. ALARM: View alarms log
On certain pages , on the top left , there is an icon with an arrow pointing to the left, when
pressed , allows return to the previous page.
8
