After a request for confirmation, the gauge will clear the readings from
the selected batch and return the gauge to the list of batches.
To clear another batch, repeat the procedure. To return the gauge
back to the previous menu, press the Back softkey.
The user can clear all batches via Batch/Edit Batch/Clear Batch/All
Batches.
Reviewing an existing batch
By selecting Batch/Review Batch the user will find a list of all the
batches that have already been created, together with the number of
readings stored in each batch.
To review a particular batch use the up and down arrow softkeys and
select the appropriate batch.
The Elcometer 224 will then open up the Review Batch menu, allowing
the user to:
?Review the statistics of the batch
?Review the batch information, including:
?the date and time the batch was created
?the batch type - normal or counted average
?the probe type and serial number used to take the readings
?the batch limits (if set)
?Review the batch’s calibration information, including:
?the date and time the batch was last calibrated or verified
?the probe type and serial number
?Review the individual readings. The Elcometer 224 displays:
?the readings in numerical order, the first reading is at the top
?icons indicating a reading above “ ” or below “ ” the limit
?deleted readings icon “ ” is displayed if “Delete With Tag”
selected
?Review a graph of all individual readings within a batch (Batch
Reading Graph), see page 23.
www.elcometer.com 22
