Electrolux WE170V - Working Phases

38
10.10.1 Working phases
Drain valve opened:
No water pressure supplied to the machine.
No power to control valve
Closing of the drain valve:
Water pressure supplied to the machine to close the drain valve.
No power to control valve
Opening of the drain valve:
Power supply to control valve to release the water pressure and let the springs open the drain valve.
