13.3 Uninstall the external liquid supply
Disconnect the power to the appliance.
To deactivate the external liquid supply: The dip switches on the external liquid supply I/O board shall be set in OFF
position.
ON
1 2 3 4 5 6 7 8
13.4 Pump signal schedule
Signal/Pump Chemical Used in Program Other info
1 Detergent
Pre wash and main
wash
2 Bleach
Main wash Normal 60 and 95
Eco 60
Disinfection 60, 70
and 85
3 Softener
Last rinse All programs except
Mop 60 and 85 and
Rinse
Can be deselected by
the user with option
button
4 Floor care
Last rinse Mop 60 and 85
Rinse
