Technical Support - DMM 59/80 599 74 98-60 Rev.00
Remove the connectors protection.
Pull out the connectors positioned beside the board.
Pull out the other connectors, taking care as they are retained by hooks.
12.2.2 Solenoid valve
Remove the worktop.
Disconnect the connectors.
Pull out the pipes which connect the solenoid valve to the detergent container.
Unscrew the water fill pipe from the solenoid valve.
Push the two retainers indicated by the arrows towards the inside of the
appliance.
At the same time, turn the solenoid valve to remove it.
12.2.3 Control panel
Remove the worktop.
