Technical Support - DMM 76/80 599 74 98-60 Rev.00
12.6.2 Plastic pulley
Remove the back panel.
Remove the belt.
Insert a retainer to secure the pulley in place.
Unfasten the screw securing the pulley to the drum shaft.
Tighten the screw at a torque of 60 Nm.
12.6.3 Inverter
Remove the back panel.
Loosen the two screws that fix it to the cabinet.
Remove the wiring from the hook of the inverter casing and move it inwards.
Turn it and position it as shown in the figure.
Push the washing unit towards the inside and remove the inverter.
Open the wiring protection and disconnect the connectors.
