Technical Support - DMM 67/80 599 74 98-60 Rev.00
12.3.5 Blade
This blade is secured to the drum with slides and secured with blades
carved into the drum.
To remove it from the drum:
Insert a flat-tip screwdriver into the central slot of the left row.
The screwdriver with the handle tilted towards the right push the left-hand tab
down.
The screwdriver with the handle tilted towards the left.
Push the right-hand tab down.
When the two tabs are down.
Move the blade towards the front of the drum, and if necessary squash the
blade at the two ends.
