Table of alarm codes
Alarm Description Possible fault Action/machine status Reset
E11 Difficulties in water fill for washing
Tap closed or mains pressure insufficient; drain hose incorrectly
positioned; water fill solenoid faulty; leaks from the hydraulic
circuit of the pressure switch; pressure switch faulty; wiring
faulty; PCB faulty.
Cycle paused Start
E13 Water leakage
Drain hose incorrectly positioned; mains pressure insufficient;
water fill solenoid faulty; leakage/blockage of pressure switch
hydraulic circuit; pressure switch faulty.
Cycle paused Start
E21 Difficulties in draining
Drain hose kinked/blocked/incorrectly positioned; drain filter
blocked/dirty; drain pump faulty; wiring faulty; PCB faulty;
current leakage from heating element to ground.
Cycle paused Start
E23 Drain pump triac faulty
Drain pump faulty; wiring faulty; PCB faulty.
Safety drain cycle – Cycle stopped
with door open
OFF
E24
Fault in “sensing” circuit of drain pump
triac
PCB faulty.
Safety drain cycle – Cycle stopped
with door released
OFF
E33
Incongruence between closure of anti-
boiling and 1st level pressure switch
contacts
Pressure switch faulty; current leakage from heating element to
ground; heating element; wiring faulty; PCB faulty.
Safety drain cycle – Cycle stopped
with door open
OFF
E35 Water overflow (flooding)
Water fill solenoid faulty; leakage from pressure switch
hydraulic circuit; pressure switch faulty; wiring faulty; PCB
faulty.
Cycle blocked. Safety drain cycle.
Drain pump always in operation (5
minutes on, 5 minutes off etc.)
OFF
E36
Fault in “sensing” circuit of anti-boiling
pressure switch
PCB faulty. Cycle blocked, door locked. OFF
E37 1st level sensing circuit faulty
PCB faulty. Cycle blocked, door locked. OFF
E39 “HV” sensor of anti-overflow level faulty
PCB faulty. Cycle blocked, door locked. OFF
E41 Door open
Door interlock faulty; wiring faulty; PCB faulty. Cycle paused Start
E42 Problems of door closure
Door interlock faulty; wiring faulty; PCB faulty. Cycle paused Start
E43 Interlock power supply triac faulty
Door interlock faulty; wiring faulty; PCB faulty. (Safety drain cycle) Cycle blocked OFF
E44 Door interlock sensor faulty
PCB faulty. (Safety drain cycle) Cycle blocked OFF
E45 Door interlock sensing circuit triac faulty
PCB faulty (Safety drain cycle) Cycle blocked OFF
E51 Motor power supply triac short-circuited
PCB faulty; current leakage from motor or from wiring.
Cycle blocked, door locked (after 5
attempts)
OFF
E52
No signal from motor tachometric
generator
Motor faulty; wiring faulty; PCB faulty
Cycle blocked, door locked (after 5
attempts)
OFF
E53 Motor triac sensing circuit faulty
PCB faulty. Cycle blocked, door locked OFF
E54 Motor relay contacts sticking
PCB faulty; current leakage from motor or from wiring
Cycle blocked, door locked (after 5
attempts)
OFF
