EN
© 2009, Elektro-Automatik GmbH & Co. KG
About the device
2.2 Technicalspecications
* Related to the nominal value
PS 8016-20 DT PS 8032-10 DT PS 8032-20 DT PS 8065-05 DT PS 8065-10 DT PS 8080-40 DT PS 8080-60 DT PS 8160-04 DT PS 8360-10 DT PS 8360-15 DT
Mains input
Input voltage 90…264V 90…264V 90…264V 90…264V 90…264V 90…264V 90…264V 90…264V 90…264V 90…264V
Input voltage with derating - - - - - - 90...150V - - 90...150V
Input current at 230V max. 1.8A max. 1.8A max. 3.2A max. 1.8A max. 3.4A max. 4.8A max. 7.5A max. 3.2A max. 7.5A max. 7.5A
Input current at 100V max. 3.8A max. 3.8A max. 7.5A max. 3.8A max. 7.5A max. 11.4A max. 11.4A max. 7.5A max. 11.4A max. 11.4A
Input frequency 45…65Hz 45…65Hz 45…65Hz 45…65Hz 45…65Hz 45…65Hz 45…65Hz 45…65Hz 45…65Hz 45…65Hz
Input fuse T 8A T 8A T 8A T 8A T 8A T 16A T 16A T 8A T 16A T 16A
Power factor > 0.99 > 0.99 > 0.99 > 0.99 > 0.99 > 0.99 > 0.99 > 0.99 > 0.99 > 0.99
Output - Voltage
Nominal voltage U
Nom
16V 32V 32V 65V 65V 80V 80V 160V 360V 360V
0V…U
Nom
0V…U
Nom
0V…U
Nom
0V…U
Nom
0V…U
Nom
0V…U
Nom
0V…U
Nom
0V…U
Nom
0V…U
Nom
0V…U
Nom
Stability at mains fluctuation ±10% ¨8
IN
< 0.02% < 0.02% < 0.02% < 0.02% < 0.02% < 0.02% < 0.02% < 0.02% < 0.02% < 0.02%
Stability at 10…90% load < 0.05% < 0.05% < 0.05% < 0.05% < 0.05% < 0.05% < 0.05% < 0.05% < 0.05% < 0.05%
Ripple
< 40mV
pp
< 40mV
pp
< 40mV
pp
< 40mV
pp
< 40mV
pp
< 70mV
pp
< 70mV
pp
< 40mV
pp
< 100mV
pp
< 100mV
pp
Accuracy*
Resolution of display 10mV 10mV 10mV 10mV 10mV 10mV 10mV 100mV 100mV 100mV
Remote sense compensation max. 2.0V max. 2.0V max. 2.0V max. 2.0V max. 2.0V max. 2.0V max. 2.0V max. 2.0V max. 2.0V max. 2.0V
Overvoltage protection
threshold (adjustable)
0…17.6V 0…35.2V 0…35.2V 0…71.5V 0…71.5V 0….88V 0….88V 0…176V 0…396V 0…396V
Output - Current
Nominal current I
Nom
20A 10A 20A 5A 10A 40A 60A 4A 10A 15A
0A…I
Nom
0A…I
Nom
0A…I
Nom
0A…I
Nom
0A…I
Nom
0A…I
Nom
0A…I
Nom
0A…I
Nom
0A…I
Nom
0A…I
Nom
Stability at mains fluctuation ±10% ¨8
IN
< 0.05% < 0.05% < 0.05% < 0.05% < 0.05% < 0.05% < 0.05% < 0.05% < 0.05% < 0.05%
Stability at 0…100% ¨8
OUT
< 0.15% < 0.15% < 0.15% < 0.15% < 0.15% < 0.15% < 0.15% < 0.15% < 0.15% < 0.15%
< 50mA
pp
< 50mA
pp
< 50mA
pp
< 50mA
pp
< 50mA
pp
< 100mA
pp
< 100mA
pp
< 50mA
pp
< 15mA
pp
< 15mA
pp
Accuracy*
Resolution of display 10mA 10mA 10mA 1mA 10mA 10mA 10mA 1mA 10mA 10mA
Transient recovery time 10….90% load < 2ms < 2ms < 2ms < 2ms < 2ms < 2ms < 2ms < 2ms < 2ms < 2ms
Output - Power
Nominal power P
Nom
320W 320W 640W 325W 650W 1000W 1500W 640W 1000W 1500W
Nominal power at <150V U
in
320W 320W 640W 325W 650W 1000W 1000W 640W 1000W 1000W
0...P
Nom
0...P
Nom
-
0...P
Nom
0...P
Nom
Adjustable range
Resolution of adjustment - - - - - 1W 1W - 1W 1W
Miscellaneous
Cooling by fan by fan by fan by fan by fan by fan by fan by fan by fan by fan
Overtemperature shutoff approx. 80°C approx. 80°C approx. 80°C approx. 80°C approx. 80°C approx. 80°C approx. 80°C approx. 80°C approx. 80°C approx. 80°C
Ambient temperature 0….40°C 0….40°C 0….40°C 0….40°C 0….40°C 0….40°C 0….40°C 0….40°C 0….40°C 0….40°C
Storage temperature -20….70°C -20….70°C -20….70°C -20….70°C -20….70°C -20….70°C -20….70°C -20….70°C -20….70°C -20….70°C
Humidity rel. < 80% < 80% < 80% < 80% < 80% < 80% < 80% < 80% < 80% < 80%
Dimensions (WxHxD) 330x118x300mm 330x118x300mm 330x118x300mm 330x118x300mm 330x118x300mm 330x118x380mm 330x118x380mm 330x118x300mm 330x118x380mm 330x118x380mm
Weight 5kg 5kg 5kg 5kg 5kg 9.5kg 9.5kg 5kg 9.5kg 9.5kg
Safety
EMC standards
Overvoltage class
Protection class
Article number 09200130 09200131 09200133 09200132 09200134 09200136 09200137 09200135 09200138 09200139
EN 61326, EN 55022 Class B
