Element4 SKY Series - Page 24

23
Appendix A
INSTALLATION MANUAL |
Figure A.H | Second thermocouple
Figure A.I | Button A on “On”
Figure A.J | RESET-button
Figure A.K | Aux-position receiver
AM
PM
ON
1 2
OFF
Figure A.L | “Double plus”-button on the remote
Figure A.M | SI-port
PANEL
G60-ZCE/1000
MA
GR
MO
SW
2
1
3
MODE
Ignition Main Burner
High Flames
Pilot
Extinguish Main Burner
Ignite second burner
Extinguish second burner
1 & 3
1
3
1, 2 & 3
1 & 2
2 & 3
CONTACT
Cable
RECEIVER
Figure A.N | Domotica system
