DD52R-E (GN 9053) - DD52R-E-RF (GN 9153)
Modelle, alle Rechte vorbehalten in Übereinstimmung mit dem Gesetz.
Bei Reproduktion der Zeichnungen, bitte immer Quellenangabe.
The available options are:
- P_OrG : direct programming of the absolute reference value (OrG parameter)
- P_StP : direct programming of the reading after one revolution (StEP parameter)
- P_OFS : direct programming of the compensation value (OFFS parameter)
- OFF : the keys combination
+
is not linked to any function in the
operating mode
For programming the parameters listed above see parameter 0____0 of
cap. 8.3.
7.5 Targets
The electronic position indicators DD52R-E allows the set up of 32 target positions
to store relevant machine configuration setting.
To program the targets:
- selet tArGEt in the main menu (see cap. 8)
- select PrOG_t (see cap. 8.4)
- select the memory location ( PtG01 to PtG32 ) by using the keys or
- press the key to select.
- follow the instructions in cap. 8.1 to set the value.
To load a target:
- select tArGEt in the main menu (see cap. 8)
- select LOAd_T (see cap. 8.4)
- select the target value ( LtG01 to LtG32 ) using the keys or
- press the key to select.
- The value of the selected target is shown.
- Press again to confirm or press to go back to the target selection list.
The keys combination
+
allows direct access to the programming or
loading of targets depending on the value assigned to parameter ___0_0 .
If enabled, the key combination allow to chose between the two following operations:
LOAd_t : choose one of the 32 available target positions, then press to
confirm.
