DD52R-E (GN 9053)
-
DD52R-E-RF (GN 9153)
Modelle, alle Rechte vorbehalten in Übereinstimmung mit dem Gesetz.
Bei Reproduktion der Zeichnungen, bitte immer Quellenangabe.
8.6.2 Test LCD
The
LcdtSt
voice in the main menu allows to switch on all the display segments
and symbols.
8.6.3 Release version
It is the last voice of the main menu.
The release number is shown with the “
r
” first letter.
By pressing the key other information aree shown, which have to be
comunicated to Elesa staff in case the support needed.
8.6.4 Password
It is possible to avoid free access to the device menu by choosing “
on
“ in the
PASS
voice of the menu.
In this case to enter the menu the password 22011 (see cap. 8.1) must be inserted.
9 Battery replacement
The internal lithium CR2477 - 3.0 V battery ensures up to 8 years battery life
(3 years for RF version).
The symbol appears on the display when the battery replacement is required.
The replacement is made by simply unscrewing the two TORX T6 screws and
by removing the front cover, with no need of disassembly the indicator from the
control shaft consequently all the configuration parameters are kept unchanged.
For removing the battery from the battery compartment, we recommend the use
of a magnet. By replacing the battery in less than 5 seconds, all the measurement
and settings are not lost. If more time is required and the display turns off, the
settings of the device have to be made or verified again.
