DD52R-E (GN 9053) - DD52R-E-RF (GN 9153)
Modelle, alle Rechte vorbehalten in Übereinstimmung mit dem Gesetz.
Bei Reproduktion der Zeichnungen, bitte immer Quellenangabe.
Parameter Description Available options Default
___0__
“ t_Sho”
Display visualization
during target mode
d_toG0 : during the
positioning, the display shows
the distance from the target.
Keep the key pressed, on
the display will appear the actual
position of the indicator.
d_tArG : during the
positioning, the display shows
the actual position, keep the key
pressed, on the display
will appear the target position
to reach.
d_toG0
tArGEt
Target options See cap. 8.5
0.0
8.3 Main menu tree
StEP 0.01 / 100.00
OriGin
See Cap. 8.5
dir
--o
o--
OFFSET
rES mm
1
0.1
0.01
Inch
1
0.1
0.01
0.001
deg
1
0.1
0.01
OFS 0
...
See Cap. 8.5
OFS 9
See Cap. 8.5
Scrolling direction
diSPL
0°
180°
SPEEd
300
600
1000
