2 System description
The electronic position indicators DD52R-E, with battery power supply, can be
used on passing through shafts in any position to provide the reading of the
absolute or incremental positioning of a machine component.
Mechanical and electrical characteristics
Power supply Lithium battery CR2477 3.0 V
Battery life Up to 5 years (3 years for RF version)
Display
6-digit LCD of 12 mm height and special
characters
Reading scale -199999; 999999
Number of decimal digits programmable
(1)
Unit of measure
mm, inches, degrees
programmable
(1)
Rotation max. speed
300/600/1000 r.p.m.
(2)
programmable
(1)
Precision 10.000 impulses/revolution
Protection level IP65 or IP67
Working temperature 0 °C ÷ +50 °C
Storage temperature -20 °C ÷ +60 °C
Relative humidity max. 95% a 25 °C without condensation
Environment indoor use
Altitude up to 2000 m
(1)
See cap. 8.1
(2)
Default: 600 r.p.m.
WARNINGS!
Higher rotation speeds to 600 r.p.m. can be maintained for short periods of time.
The value of the max speed affects the battery life.
