DD52R-E (GN 9053) - DD52R-E-RF (GN 9153)
Modelle, alle Rechte vorbehalten in Übereinstimmung mit dem Gesetz.
Bei Reproduktion der Zeichnungen, bitte immer Quellenangabe.
Select the:
ABS: absolute measuring mode
REL: incremental measuring mode
It is possible to choose one of the following
options (see the __0___ voice of the
menu – cap. 8.3):
ArCLr [DEFAULT]: switching from ABS to
REL the counter is set to zero.
Ar: switching from ABS to REL the counter is
not set to zero.
OFF: the key is not assigned to any function
in the operating mode.
Digit decrease /
Scroll for parameters
top-bottom on the
menu tree
Press the key to select the unit of measure
needed. The options available are: millimeters,
inches and degrees.
It is possible to choose one of the following
options (see the 0_____ voice of the
menu – cap. 8.3):
ALL [DEFAULT]: selectable units of measure:
mm, inch, D
nodEG: selectable units of measure: mm, inch
OFF: the key does not allow the unit of
measure conversion
Programming mode
exit /
Digit selection
+
Programmable with one of the following
options (see the 0____0 voice of the
menu – cap. 8.3):
P_OrG [DEFAULT]: show and set the OriGin
parameter
P_StP: show and set the StEP parameter
P_OFS: show and set the OFFS parameters
OFF: the key combination is not assigned to
any function in the operating mode.
N/A
+
Programmable with one of the following
options (see the __0__0 voice of the
menu – cap. 8.3):
L_OrG [DEFAULT]: the key combination
sets the absolute value to the sum of the
parameters Origin and Offset.
OFF: the key combination is not assigned to
any function in the operating mode.
N/A
