3 Technical Parameters
30
S0-SCR Interface module for ENCODER – SCR 16F
ELCOR
ELCORplus
- Max. number of modules in the
device
1
1
- Installation in the device
SLOT 0
SLOT 0
- Number of inputs
1
- Connection
Two-wire
- Type
SCR+
- Communication protocol supported
OBIS 2005 (IEC 62056-21 Mode A)
(EDIS (IEC1107 Mode A))
- Terminals marking
SLOT0 Terminals A (1), B (2)
- Cable length
30 m max.
Note: The module installation is protected by a MID security mark.
3.11.2 Communication Modules
S1-COM1 Communication module RS232/RS485
ELCOR
ELCORplus
- Max. number of modules in the
device
0
2
- Installation in the device
-------
SLOT1, SLOT2
- Galvanic separation
Yes
- Serial communication interface
RS485 or RS232 (cannot be used simultaneously)
- Communication protocol
Selectable, depending on the firmware version (see
Section 10)
- Communication speed
2 400 Bd to 115 200 Bd, adjustable
- Byte format
8 bits, 1 stop, no parity
- RS232 communication output
- Marking of the terminals
SLOT1,2 terminals GND (3), CTS (4), RxD (5), TxD
(6)
- Connection via IS separator
B-RS module, or MTL5051
- Cable length
30 m max.
- RS485 communication output
- Marking of the terminals
SLOT1,2 terminals D+ (1), D- (2), GND (3), U+ (4)
- Connection via JB separator
B-RS module
- Max. cable length
100 m max.
S4-COM0 RS232 communication module
ELCOR
ELCORplus
- Max. number of modules in the
device
1
1
