ELNA 2003 - STRETCH STITCH FEED BALANCE

20
STRETCH STICH FEED BALANCE
1. Remove the cap A with a needle.
2. Set stitch length at “4” and select overlock stitch.
3. Check the balancing of the stitch by sewing (see pattern stitch B).
4. Turn the adjusting screw to the direction of
C when the stitch pattern is distorted.
D when the stitch pattern is compressed
5. Recheck the balancing before attach the cap A.
A
A
DC
C D
Model 2005,2007 Model 2003
