105U-G Wireless Gateway User Manual
Page 17 © August 2003
I/O Register Description
4300 Input value DIO 1
4301 Input value DIO 2
4302 Input value DIO 3
4303 Input value DIO 4
4304 Input value DIO 5
4305 Input value DIO 6
4306 Input value DIO 7
4307 Input value DIO 8
4308 Low battery voltage status
4309 Supply voltage fail status
4310 Battery voltage value
4311 Supply voltage value
I/O Register Description
4320 Output value DIO 1
4321 Output value DIO 2
4322 Output value DIO 3
4323 Output value DIO 4
4324 Output value DIO 5
4325 Output value DIO 6
4326 Output value DIO 7
4327 Output value DIO 8
2.4 The Host - 105G Link
For the host device, the 105G "looks" like a PLC (or a "virtual PLC"), containing the I/O for
the complete wireless I/O system.
DATABASE
I/O
"VIRTUAL PLC"
DATA-BUS
“HOST DEVICE”
105U-G
