Power Status
In this section you can view all the Power Status:
Powered by: Informs the user as to the type of p ower c urrently s upplying
the instrument
AC: AC status
PoE Input: Status of the PoE on the LAN1 port; an alternate power input for
the instrument
DC (48v): Status of the DC Power Supply Input
Down: Should this f lag i ndicate " ON" it m eans that the G4K ha s no p ower
supply & is on ride through power supplied by the capacitors
Capacitors: Indicates t he si ze o f t he S uper C apacitor su pplying t he r ide
through power
SEE ALSO
G4K Unit Configuration
G4K Product Attributes
PoE Output
Alarms
