About Network Setup
The N etwork s etup is a cr ucial p art o f y our G4 K BLA CKBOX's u nit c onfiguration.
This setup procedure establishes the IP Address of your G4K Unit in the network.
The procedure includes:
 Assign an IP Address for LAN 1 Port
 Connect G4100 RTU via LAN 2 Port (if applicable)
 Make allowances for Remote Access by configuring the Port Setup
 Send Data & Notifications from your G4K unit by providing Outer Access
 Set up ports for Data Retrieval from the G4K Device via Modbus Protocol
 Set up port for Data Retrieval from the G4K Device over the Ethernet
 View the Status Summaries of your G4K Device's Network Configurations
OPEN THE NETWORK WINDOW
 Access G4K Device Configuration via Elspec's Web Interface log on as the
Administrator (Manufacturer’s Default Password is: 12345) select the
Configuration Tab
 Under Communication select the Network Tab:
