Voltage Connections
Five terminals are available for the voltage sampling inputs on the DSP Module of
the G4K. They are marked as L1, L2, L3, N, & . Each of the 4 inputs (V1, V2,
V3, N) are capable of receiving electrical signals of up to 1KV continuous RMS (up
to 8KV transient). In order to wire voltage connections, follow the following
procedure:
Install an over current device on the AC phase lines:
Remove the Voltage Terminal Block Connector provided with the G4K Unit:
