 After selecting Create New Events naming the event in Description
select to open the Condition Window:
 Name the Condition & you will need to create a Single Condition in order to
create Multiple Conditions:
 ID: The ID Condition is identified by a text ID. Two conditions cannot
be set to the same ID string.
 The Single-Type Condition: Defined as t he r esult o f so me r ule
(mathematical o peration on so me sy stem p arameters). Fo r instance,
a percentage voltage drops below the threshold or a change of digital
input & so on. The condition has 2 logic states, Activated (1) and De-
activated ( 0). T ransition t o each s tate is f ully co nfigurated b y t he
user.
 A Multiple-Type Condition: Is the c ombination o f 2 o ther s ub
conditions. A M ultiple-type co ndition m ust b e li nked t o 2 su b
conditions, each o f t hese 2 sub conditions can be either M ultiple o r
Single ty pe. T herefore, t he M ultiple-type condition c an b e u sed t o
create a complex hierarchy of conditions.
 Go to the next steps creating Single Conditions &/or Multiple Conditions
