The G4 K B LACKBOX i s i ntended to b e mounted within an enclosure, or can be
fastened either to a DIN Rail or to a F lat Surface. The physical dimensions of the
G4K are: 17.5 x 23.2 x 13.8cm (6.9 x 9.1 x 5.4”) & it weighs 1.7Kg (3.7lbs).
FASTENING THE G4K BLACKBOX TO A DIN RAIL
This i s the m ost c ommon m ounting m ethod & y ou w ill ne ed t he Clamping Yoke
Holders provided with G4K & the unit itself - see Components & Accessories.
Connect the Clamping Yoke Holders to the sides of the back plate of the
G4K using the 2 screws provided,
Attach the entire unit with the holders to the DIN Rail:
FASTENING THE G4K BLACKBOX TO A PLATE
The G4 K BLACKBOX can b e d irectly m ounted t o a plate us ing 4 x s tandard 7 mm
(0.27”) screws.
The distance of the screws on the G4K plate is (H x W) 10 x 12cm (3.9 x
4.7”). Ensure the plate has corresponding holes,
Simply screw the G4K unit onto the plate at the corresponding holes:
Successfully Mounted G4K Unit
