Table 2.17 —Light indication of copper and SFP interface status
SPEED indicator is lit
LINK/ACT indicator is lit
Ethernet interface state
Off
Off
Port is disabled or connection is not
established
Off
Solid on
10Mbps or 100Mbps connection is
established
Solid on
Solid on
1000Mbps connection is established
X
Flashes
Data transfer in progress
The following table lists description of system indicator statuses and meanings.
Table 2.18 —Status of system indicators
Indicator
name
Indicator function
LED State
Device State
Status
Current device status indicator.
Green
Device is in normal operation state.
Orange
Device is booting up the software.
Alarm
Device alarm presence and level
indicator.
1
-
-
Power
Device power indicator.
Green
Device power is OK. Main power
supply, if installed, is operational.
Orange
Main power supply failure or fault, or
the primary main is missing.
Off
Device internal power supply failure.
Fan
Cooling fan status.
Off
All fans are operational.
Red
One or more fans has failed. Possible
cause of failure: at least one of the fans
has stopped or is working at lower
rpm.
2.5 Delivery Package
ESR-100 standard delivery package includes:
 ESR-100 router
 Power cable
 Console port connection cable (RJ-45 – DB9F)
 19” rack mounting kit
 Documentation
ESR-200 standard delivery package includes:
 ESR-200 router
 Power cable
 Console port connection cable (RJ-45 – DB9F)
 19” rack mounting kit
 Documentation
1
Not supported in the current firmware version.
